Technical data
| Characteristics | CCZA | CCZB | CCZC | CCZD |
|---|---|---|---|---|
| Exact volume (cm³) | 1984 | |||
| Power system | Direct injection | |||
| Power (hp) | 200 | 211 | 170 | 180 |
| Torque (Nm) | 280 | |||
| Cylinder block | Cast iron R4 | |||
| Cylinder head | Aluminum 16v | |||
| Cylinder diameter (mm) | 82.5 | |||
| Piston stroke (mm) | 92.8 | |||
| Compression ratio | 9.6 | |||
| Hydrocompensators | Yes | |||
| Transmission timing | Chain | |||
| Fasoregulator | Inlet | |||
| Turbocharger | KKK K03 | |||
| Oil volume (l) | 4.6 (5W-30) | |||
| Ecological class | Euro 5 | |||
| Resource (km) | 275,000 | 260,000 | 260,000 | 250,000 |
| Weight (kg) | 142 |
Cars with these engines
- CCZA: Audi A3, TT, Skoda Octavia, Superb, VW Golf 5, Eos, Jetta 6, Tiguan, Sharan.
- CCZB: Seat Altea, Leon, VW Golf 6, Eos, Beetle, Scirocco, Passat B7, Passat CC, Tiguan.
- CCZC: Audi Q3, VW Tiguan.
- CCZD: VW Tiguan.
Disadvantages, breakdowns and problems
- High oil consumption due to piston ring seizure.
- Fast pulling out of the timing chain (less than 100 000 km).
- Coking of the engine due to oil loss.
- Weak fuel injector (presence of gasoline in the oil).
- Failure of ignition coils, oil pump and pump.
- Problematic plastic water pump (CCZC, CCZD).
